Материнcька плата ASUS TUF GAMING B760-PLUS WIFI s1700 B760 4xDDR5 M.2 HDMI DP Wi-Fi BT ATX

Опис

Documentation 1 x TUF Certification card 1 x User guide Операційна система Windows® 11, Windows® 10 64-bit Форм-фактор ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) 36 місяць В'єтнам

Характеристики

Модель

TUF GAMING B760-PLUS WIFI

Процесор

Intel® Socket LGA1700 for 13th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors*
Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
* Refer to www.asus.com for CPU support list.
** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.

Чіпсет

Intel® B760 Chipset

Пам’ять

4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
* Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support under the Support tab or visit https://www.asus.com/support/
* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.

Графічна система

1 x DisplayPort**
1 x
